Specifically designed to protect CGC high performance Antennas in challenging habitats, such as wind, sand or snow without hindering functionality.
[ jump to ]
Optimal resilliance and high functionality is the goal when drafting Radomes to protect against the elements. Radome designs vary depending on the challenges of the Antenna site and atunment to frequencies of interest. We have a standard array to fit our range of Antennas, or our Radomes can be supplied individually. All come with the following features:
Corrosion provention galvanised steel frame
Super lightweight yet robust construction
Low cost, high performance design
Single or multi frequency capable
Perfect for adverse environments
We construct three types of Radome [ which are expanded upon below ], The A Sandwich, C Sandwich [ both foam core ] and The Space Frame. All types account for differing thermal and frequency challenges.
The shape is most commonly configured with an icosidodecahedron, pseudo-random panel pattern, which can be tuned for specific frequencies, and helps to prevent coherent scattering.
Finite Element Analysis (FEA) is regularly adopted review the Radome shape and design, develop optimum bolting patterns, simulate the effects of snow loading and to demonstrate the impact of any design developments.
Our designs are drafted, built and tested by our own dedicated team of specialist Engineers at the 100,000+sq.ft. CGC Design facillity in Hampshire.
Three Layer system
Ideal for lower frequencies and unfavourable conditions
Two skins [ 1mm thickness each]
One foam core [ 6.5mm thickness ]
Moulded shell contruction
High gain maintained
Refelective gel coating [ Tedlar also availavle ]
Low loss
For full specifications, please contact us.
Five Layer system
Ideal for lower frequencies and more adverse conditions
Two externally facing skins [ 1mm thickness each ]
Two foam cores [ 6.5mm thickness each]
One central layer
Moulded shell contruction
High gain maintained
Refelective gel coating [ Tedlar also availavle ]
Low loss
For full specifications, please contact us.
Durable PTFE Fabric system
Ideal for higher frequencies and very low loss
Fiberglass framing
Reinforced PTFE [ Teflon ] fabric panel
High gain maintained
Refelective gel coating [ Tedlar also available ]
Lowest loss possible
Dielectric Constant: 2.8
Loss Tangent: 0.005
For full specifications, please contact us.
